XAVIS Co., Ltd. is a global technology leader and a pioneer in X-ray Inspection systems for the electronics and semiconductor industry.

Founded by developers with years of experience in developing X-ray, Machine Vision, and factory automation (FA) equipment. The Xavis inspection systems are designed to provide accurate and reliable data for quality control and process optimization.

Often used in the following applications:

  • PCB Assembly Inspection
  • Package Inspection
  • Failure Analysis

XScan A-Series


Xavis

XSCAN-A100R

Voltage/Current: 100kV / 250uA

Compact dimension using by Flat Panel Detector comparing to Image Intensifier minimized the Magnification using by Detector Tilt comparing to table tilt available to Large Size PCB.

  • 2D/3D Hybrid Inspection System with Automation Technology
  • Precise results using high-speed OCT technology
  • Built for user convenience: S/W, Table Size, etc. can be customized according to users and applications.

Features

  • High Resolution FPD (Flat Panel Detector)
  • Detector Tilt (50˚)
  • Large PCB size Available
  • Navigation User interface (CNC Programming)
  • Real 3D CT (option)
  • Tube Focus Size : 5㎛
  • World class High resolution X-ray image
  • Various Optional Functions (Rotation, CT, 3D)
  • Easy to Use & User Friendly Operation
Xavis

XSCAN-A130H

Voltage/Current: 130kV / 300uA

Compact dimension using by Flat Panel Detector comparing to Image Intensifier minimized the Magnification using by Detector Tilt comparing to table tilt available to Large Size PCB.

  • 2D/3D Hybrid Inspection System with Automation Technology
  • Precise results using high-speed OCT technology
  • Built for user convenience: S/W, Table Size, etc. can be customized according to users and applications.

Features

  • High Resolution FPD (Flat Panel Detector)
  • Detector Tilt (50˚)
  • Large PCB size Available
  • Navigation User interface (CNC Programming)
  • Real 3D CT (option)
  • Tube Focus Size : 5㎛
  • World class High resolution X-ray image
  • Various Optional Functions (Rotation, CT, 3D)
  • Easy to Use & User Friendly Operation

XScan H-Series


Xavis

XSCAN-H100-OCT

Max Power Output:20W

5 Inch Flat Panel Detector (2,352 x 2,944 pixels) X-ray Inspection System

  • 2D/3D Hybrid Inspection System with Automation Technology
  • Precise results using high-speed OCT technology
  • Built for user convenience: S/W, Table Size, etc. can be customized according to users and applications.

Applications

  • PCB, SMT, LED, Semiconductor, LCD, Automotive, Battery
  • μBGA ,BGA, CSP, ACF, Flip-Chip ,FPCB etc
Xavis

XSCAN-H130-OCT

Max Power Output:35W

5 Inch Flat Panel Detector (2,352 x 2,944 pixels) X-ray Inspection System

  • 2D/3D Hybrid Inspection System with Automation Technology
  • Precise results using high-speed OCT technology
  • Built for user convenience: S/W, Table Size, etc. can be customized according to users and applications.

Applications

  • PCB, SMT, LED, Semiconductor, LCD, Automotive, Battery
  • μBGA ,BGA, CSP, ACF, Flip-Chip ,FPCB etc
Xavis

XSCAN-H160-OCT

2D & 3D Offline High Resolution X-Ray Inspection System

  • 2D/3D Hybrid Inspection System with Automation Technology
  • Precise results using high-speed OCT technology
  • Built for user convenience: S/W, Table Size, etc. can be customized according to users and applications.

Applications

  • PCB, SMT, LED, Semiconductor, LCD, Automotive, Battery
  • μBGA ,BGA, CSP, ACF, Flip-Chip ,FPCB etc

XSCAN-4280


Xavis

XSCAN-4280

Inspection Area: 380mm

Applications

  • Belt Type In-Line
  • Automatic X-Ray Inspection

XSCAN-9843/9845


Xavis

XSCAN-9843/9845

Applications

  • Belt Type In-Line
  • Automatic X-Ray Inspection
